Description
The GPA-500MG automatic gas pasteurizer is designed to heat liquid, low viscosity foods and non-carbonated beverages. The pasteurizer is possible to use also as an equipment for heat treatment of drinking water.
The machine has been designed accordance with security requirements valid in European union. Operation capacity is up to 500 liters per hour.
The heat exchanger ensures the heat treatment of beverages using a fitted stainless steel tube in tube (the coaxial system).The heat is provided by a gas boiler. The heating water temperature is controlled by the automatic control system. The temperature of the treated liquid is controlled by a by-pass valve. Temperature check at two points, in the heat exchanger and once on the outlet.
The pasteurizer works fully automatically.
The machine automatically controls the heat exchanger temperature. If the temperature of the beverage falls below the desired temperature, the machine disabled and the beverage circulates in the by-pass system until the temperature reaches the set level.
At the end of the work, the tube spiral can be cleaned very easily with the help of a sponge ball.
It requires minimal maintenance.
Technical parameters :
- Performance: 500 L/h (When heated from 20 °C to 80 °C)
- Electric demands: 1 kW, 230 V, 6 A
- Heat performance: 55 kW
- Fuel: propane, PB, natural gas
- Material: Wnr. 1.4301, AISI 304 stainless steell
- Weight: 350 kg
- IP65 certified electronics
- Connections: DN 25
- Flue gas discharge:: 110 mm diameter
- Automatic temperature control
- Automatic by-pass system
- Easy to clean with sponge balls
- Requires minimal maintenance
Dimensions :
(the pasteurizer with the optional buffer tank)
Variants and optional equipment :
Code |
Name |
Description |
GPA-500MG-WOF |
Pasteurizer without accessories |
The fully automatic flow-through pasteurizer 500L/hr for pasteurization of non-carbonated beverages or usable to heat treatment of drinking water
|
GPA-500MG-BT |
Pasteurizer with integrated buffer tank |
The buffer tank is fully automatic and communicates with the pasteurizer. If the level of the beverage is too low the system will automatically shut down temporarily until the tank is full and then the process starts again. It can work with both bottle filler at the same time. The buffer tank is placed above the pasteurizer.
|
GPA-500MG-BFU |
Pasteurizer with the integrated automatic buffer tank and the integrated semi-automatic 6-head bottle filling unit |
Automatic gas pasteuriser 500 liters/hr (for non-carbonized beverages) – with the integrated fully automatic buffer tank and the integrated semi-automatic 6-head bottle filling unit intended to gravity filling of drinks into glass or PET bottles.
|
GPA-500MG-BIB18 |
Pasteurizer with the integrated automatic buffer tank and the integrated semi-automatic BIBFU-180 Bag-in-Box filling unit |
Automatic gas pasteuriser 500 liters/hr (for non-carbonized beverages) – with the integrated fully automatic buffer tank and the integrated semi-automatic filling unit BIBFU-180 intended to gravity filling of drinks into Bag-In-Box packages or Pouch-Up bags. Filling capacity from 255 up to 500 liters per hour (depending on the bag type).
Description of the BIBFU-180 filling unit …
|
GPA-500MG-BIB29 |
Pasteurizer with the integrated automatic buffer tank and the external semi-automatic BIBFU-290 Bag-in-Box filling unit |
Automatic gas pasteuriser 500 liters/hr (for non-carbonized beverages) – with the integrated fully automatic buffer tank and the external semi-automatic filling unit BIBFU-290 intended to gravity filling of drinks into Bag-In-Box packages or Pouch-Up bags. Filling capacity from 390 up to 3000 liters per hour (depending on the bag type).
Description of the BIBFU-290 filling unit …
|
GPA-500MG-BIB32 |
Pasteurizer with the integrated automatic buffer tank and the external semi-automatic BIBFU-320 Bag-in-Box filling unit |
Automatic gas pasteuriser 500 liters/hr (for non-carbonized beverages) – with the integrated fully automatic buffer tank and the integrated semi-automatic filling unit BIBFU-320 intended to gravity filling of drinks into Bag-In-Box packages or Pouch-Up bags. Filling capacity from 420 up to 3600 liters per hour (depending on the bag type).
Description of the BIBFU-320 filling unit …
|
Recommended connection scheme for use the machine as a flow-through pasteurizer (without the filling unit and the buffer tank)
Accessories:
- Sponge balls for cleaning
Delivery time :
- Usual delivery time is 60 days from first payment.
Warranty time :
- 12 months
