PMX-VER4SD : Postmix Ver4SD – NEW | Soft drink production machine : four drinks + cold soda + water

Postmix PMX-VER4SD is ​​a special device that is used for the quick and convenient production of lemonades, juices or other fruit drinks using concentrated syrup and freshly prepared soda water.
The Postmix PMX-VER4SD allows you to produce and immediately offer cheaply and quickly four different flavored drinks, cold soda and water. It also offers the possibility of mixing syrups with water or soda.

You can immediately offer fresh and refreshing drinks with a sufficiently large production capacity.



Detailed description of the Postmix VE4SD :

• The postmix VER4SD lemonade production and bottling equipment is literally loaded with functions. Compared to other types, it can mix syrups with soda and cold water.
• The postmix VER4SD is generally designed to produce four types of different drinks and bottling chilled water and soda water.
• The postmix is controlled by mechanical buttons on a glass panel with backlit fields for flavor and beverage symbols, which gives the device a modern touch.
• The use of innovative technology allows you to electronically set syrup ratios, portion sizes, monitor the amount of dispensed drinks and monitor the condition of the water filter.
• Connections for common drinking hoses with an outer diameter of 3/8″ (9.5mm)
• The use of this modern technology allows users to electronically set syrup ratios, portion sizes, monitor the amount of drinks dispensed, and newly also produce juices (mixing syrups with cold water).
• The heat exchanger of the cold is an aluminum block in which is the carbon dioxide saturator, stainless steel evaporator and beverage bellows are embedded.
• The inlet connection at the bottom of the device allows water, syrups and CO2 to be supplied from any side.





Technical parameters :

• 6 chilled drinks – 4 flavored drinks + water and soda (possibility of mixing syrups with water or soda)
• Mechanical buttons on the glass control panel
• Electromagnetic tap head
• Stainless steel casing
• Robust construction
• Cooling capacity of the device: 35 l/h
• Dimensions width/depth/height: 280/ 477/ 442 mm
• Weight: 35 kg





To connect the post-mix you need:

• Water line : water supply regulations – connection to a tap with a 1/2 thread (preferably within 5 m of the soda bar), the water at the inlet must meet the pressure and quality criteria
• Gas line : CO2 pressure cylinder
• Electricity : standard electrical outlet (within 1.5 m from the machine)
• Syrups : in bag-in-boxes or in cuvettes

For postmix, we recommend purchasing a set of accessories according to the used syrup package for its connection and operation!
