BWM-SA266 : Semi-automatic bottle washing machine for 6+6 bottles, 2-phases (chemical detergent + rinsing with water), heating 3kW

 4299 5589 excluding tax

The stainless steel double-phase semi automatic bottle washer makes washing and chemical cleaning new bottles very easy. The machine is designed for the needs of small businesses. With a clear and simple operation, the bottle washer is the perfect solution for cleaning inner surfaces of new or only little dirty used bottles.
The machine can wash 6 bottles with one chemical detergent filled in the heated 65 liter tank and 6 bottles at the same time with cold water (we recommend to use treated water filtered by a filter 1 micron). Automatic washing heads, automatic timing of the washing time.
The machine is equipped with 3kW electric heating built in the 65-liter tank for a chemical detergent.

We offer this machine in two variants according to the stainless steel material which is the machine made of.
The variant BWM-SA266-304 is fully made of AISI 304 stainless steel. We recommend it for use with cold chemical detergents (heating maximally to 30°C) in very small concentration (NaOH or H2SO4 in concentration maximally 2%).
The variant BWM-SA266-316 is partitialy made of AISI 316 stainless steel, only parts which do not come in contact with detergent are made of AISI 304. We recommend it for use with hot water or hot chemical detergents (heating maximally to 70°C) and higher concentration of chemical (NaOH in concentration maximally 6%).

Clear selection

Description

The stainless steel double-phase semi automatic bottle washer makes washing and chemical cleaning new bottles very easy. The machine is designed for the needs of small businesses. With a clear and simple operation, the bottle washer is the perfect solution for cleaning inner surfaces of new or only little dirty used bottles.
The machine can wash 6 bottles with one chemical detergent filled in the heated 65 liter tank and 6 bottles at the same time with cold water (we recommend to use treated water filtered by a filter 1 micron). Automatic washing heads, automatic timing of the washing time.
The machine is equipped with 3kW electric heating built in the 65-liter tank for a chemical detergent.

We offer this machine in two variants according to the stainless steel material which is the machine made of.
The variant BWM-SA266-304 is fully made of AISI 304 stainless steel. We recommend it for use with cold chemical detergents (heating maximally to 30°C) in very small concentration (NaOH or H2SO4 in concentration maximally 2%).
The variant BWM-SA266-316 is partitialy made of AISI 316L stainless steel, only parts which do not come in contact with detergent are made of AISI 304. We recommend it for use with hot water or hot chemical detergents (heating maximally to 70°C) and higher concentration of chemical (NaOH in concentration maximally 6%).







Technical parameters :

Variant BWM-SA266-304

  • 6 bottle positions for washing with a cold or warm chemical detergent (NaOH or H2SO4 in concentration maximally 2%, heating maximally to 30°C) – circulation ensured with a built-in pump, the used detergent is returned back to the inner tank
  • 6 bottle positions for rinsing with cold water (we recommend to use treated water filtered by a filter 1 micron) – it requires a connection on pressure water, the used water is drained out to sewage

Variant BWM-SA266-316

  • 6 bottle positions for washing with a cold or hot chemical detergent (NaOH or H2SO4 in concentration maximally 6%, heating maximally to 70°C) – circulation ensured with a built-in pump, the used detergent is returned back to the inner tank
  • 6 bottle positions for rinsing with cold water (we recommend to use treated water filtered by a filter 1 micron) – it requires a connection on pressure water, the used water is drained out to sewage



  • Automatic bottle washing heads
  • Adjustable bottle washing time
  • With the heating system (the inner tank for chemical is equipped with the electric heating)
  • Suitable for bottles with capacity from 0.2 liters up to 1.5 liters
  • One chemical detergent in the tank with capacity of 65 liter – circulation ensured with a built-in pump, the used detergent is returned back to the inner tank
  • Rinsing with cold pressure water – it requires a connection on pressure water, the used water is drained out to sewage
  • Centrifugal pump with the stainless steel parts in contact with the chemicals
  • Electric supply voltage : 3-phase 400V 50Hz
  • Electric heating : 3kW
  • Electric power consumption : 3375 W
  • Material : AISI 304 stainless steel (version  BWM-SA266-304) / AISI 316L stainless steel (version  BWM-SA266-316)



Dimensions :

  • Dimensions : 1020x910x660 mm
  • Weight : 120 kg



BWM-SA212 : Semi-automatic dishwasher for 12 bottles, 2 chemical solutions



Hose connections on the machine :

Description (purpose) Hose connection on the machine Intended for
Filling the tank with water Hose nipple 1/2″ Hose 1/2″



Packing material : € 55,-





Additional information

Weight 135 kg
Dimensions 1200 × 1000 × 800 mm
Material

AISI 304, AISI 316L
