SBP-400MG : Single belt fruit press 400 kg/h

The single belt press FBP-400MG is designed for pressing of fruit mass. Fruit mass is placed on the continuous belt which presses it against cylinders. The obtained juice flows in the collection trays under the press. Production capacity up to 400 kg of fruit per hour.

Main properties and demands :

• Entirely made of stainless steel AISI 304 / 1.4301
• Continual pressing process.
• Yield up to 75% (depending on the kind, freshness and quality of the fruits)
• Low oxidation and high quality of must and cider
• Pressing of  fruit with a gradual increase of pressure
• Variable speed of the belt
• IP65 certified electronics
• Food industrial, massive polyester belt – 2mm thick, density: 6×16 filament/cm2, ½ rate (suitable for large fiber-free juice)
• High-pressure washer demand: 360 L/h
• Compressed air demand: 50 L/h 6 bar
• Built-in inverter: steplessly adjustable belt speed
• Fully automatic operation, with closed work area, reduces the fruit mash oxidation to the minimum.
• In the bottom of the machine, there are two spinning washer heads guarantees optimal cleaning during the process.
• The distance between the press cylinder and the juice collector tray is reduced to avoid the fruit juice foaming.
• The belt press can be disassembled without any tools in few minutes!
• Very easy to clean.
• With 4pcs of the adjustable vibration-free feet.
• Requires minimal maintenance.
• Both an external high-pressure washer and air compressor are essential for operating.

Technical parameters  :

Hose connections on the machine :

Optional and spare parts  :
