Description
The BDT-CL3T-ECS beverage dispense tower designed for 3pcs of the standard beer faucets (connection thread 5/8″). Produced fully of stainless steel, outer design : copper. With standard cooling of the beverage taps which ensures the maximum quality of a drink on each faucet.
Technical description :
The beverage dispense tower is supplied without taps and without medallions (drink plaque holders)
Standard cooling of beverage lines
Designed for luxury restaurants, pubs, microbreweries, wine bars.
Version for 3 beverage taps
Made entirely of AISI 304 stainless steel.
Color design – copper outer design
Stainless steel inner pibes – 7×8 mm
Stainless steel recirculation loop – 7×8 mm
Option to deliver with direct cooling of taps (for an extra charge)
Possibility to deliver with stainless steel pipes with a size of 10×11 mm (for an extra charge)
Different types of taps can be chosen
Spacing between beverage taps : 140 mm
Taps with horizontal control ROYAL, GLOBAL, NOSTALGIA, BAROQUE can be used
Option to add plaque holders with LED lighting
Stand body diameter: 102 mm
Height of the faucet axis: 458 mm
Spacing between the holes for the beverage faucets : 140 mm
Connection threads: BSP 5/8″ female
Dimensions :
All dimensions are in milimeters.
Recommended accessories :
BTM-TID-I : Titanum-plated medailon – simple (drink placquet)
Copper medailon (drink placquet) with LED backlighting
The medailon is welded on the stand and it is necessary to order it with the beverage dispense stand. This accessory is not orderable separatelly.
Beverage dispense taps
Cooling system for beverage lines
Fully equipped the Classic-L3 beverage dispense tower (copper design) :
